SUB-MICRON
Our spunbond nylon 6,6 substrates exhibit high tensile strengths and exceptional uniformity. As you would expect, substrate uniformity has a direct impact on the quality and consistency of the sub-micron media laydown application. The smaller mean pore size of our nylon spunbond substrates have proven to work extremely well with a wide variety of media designs while providing outstanding flow properties.
In addition, the exceptional strength and uniformity is excellent when producing medias with sub-micron efficiences. Benefit from the unique properties of our nylon 6,6 substrates and make it your first choice when designing your next media composite.
The Nylon Advantage®
One of the Toughest and most durable man-made polymers
High tensile and tear strength even at low fabric weights
Extreme thermal stability and high melting points
Resistant to most chemicals, solvents, alkalis, and acids
Excellence in uniformity and high quality applications
About Our Products
Cerex Advanced Fabrics Inc. is focused on developing and producing high quality products and providing world-class service.
We are certified to industry-leading quality assurance systems including ISO 9001 to maintain strong technical capabilities throughout the organization.
Our propriety process technology produces highly uniform and very strong nonwoven fabrics.
Cerex® Type 23100
Our flat bond Cerex® fabrics provide unparallelled uniformity and strength as compared to PET. Since substrate uniformity has a direct impact on the quality and consistency of the sub-micron media layer during processing, use the best….Use Cerex® substrates.
- Flat Bonded Nylon 6,6
- Fabric Color – Natural
- Weight – 1.0 osy / 34 gsm
- Grab Strength – 36.8 Lbs / 164 N
- Burst Strength – 34.5 Lbs / 237.9 kPa
- Thickness – 5.4 mils / .14 mm
Cerex® Type 23150
Our flat bond Cerex® fabrics provide unparallelled uniformity and strength as compared to PET. Since substrate uniformity has a direct impact on the quality and consistency of the sub-micron media layer during processing, use the best….Use Cerex® substrates.
- Flat Bonded Nylon 6,6
- Fabric Color – Natural
- Weight – 1.5 osy / 51 gsm
- Grab Strength – 58.4 Lbs / 260 N
- Burst Strength – 50.7 Lbs / 349.6 kPa
- Thickness – 6.9 mils / .18 mm
Cerex® Type 23200
Our flat bond Cerex® fabrics provide unparallelled uniformity and strength as compared to PET. Since substrate uniformity has a direct impact on the quality and consistency of the sub-micron media layer during processing, use the best….Use Cerex® substrates.
- Flat Bonded Nylon 6,6
- Fabric Color – Natural
- Weight – 2.0 osy / 68 gsm
- Grab Strength – 73.6 Lbs / 327 N
- Burst Strength – 67.1 Lbs / 462.6 kPa
- Thickness – 8.4 mils / .21 mm
Cerex® Type 23200
Our flat bond Cerex® fabrics are preferred in many high-end performance applications which require superior strength and uniformity. The exceptional thermal and chemical resistance of our products provide an excellent substrate for all media materials.
- Flat Bonded Nylon 6,6
- Fabric Color – Natural
- Weight – 2.0 osy / 68 gsm
- Grab Strength – 73.6 Lbs / 327 N
- Burst Strength – 67.1 Lbs / 462.6 kPa
- Thickness – 8.4 mils / .21 mm
Our Certifications
Products Certifications
- Berry Amendment Materials Certification
- Boeing® Certification
- Oekotex® Standard 100
- Flammability Certification (FMVSS302)
- EPA 40CFR300-15 Sorbent Approval
- FDA Continuing Letter of Guarantee
Company Certifications
- ISO 9001
Product Stewardship
- REACH/ECHA SVHC Compliance
- RoHS Compliance
- Dodd-Frank Act Compliance
- CONEG Compliance
- Prop69 Compliance
